MGVCL Exam Paper (30-07-2021 Shift 2)
____are long-term (hours-long) voltage sags caused by system overload.

Brownouts
Voltage surges
Voltage dips
Black outs

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP

MGVCL Exam Paper (30-07-2021 Shift 2)
In transformer, a Sweep Frequency Response Analysis (SFRA) test will help detect ____

Movement / damage to internal components
Age of the insulation
Moisture in the windings
Aging by-products

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP

MGVCL Exam Paper (30-07-2021 Shift 2)
In a short circuit test on circuit breaker, time to reach the peak re-striking voltage is 50 µs with the peak restriking voltage of 100 kV. Determine average RRRV (Rate of rise re-striking voltage)?

1 x 10⁶ kV/sec
2 x 10⁶ kV/sec
3 x 10⁶ kV/sec
4 x 10⁶ kV/sec

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP

MGVCL Exam Paper (30-07-2021 Shift 2)
The line currents in amperes in phases a, b and c respectively are 500 +j150, 100 – j600 and – 300 + j600 referred to the same reference vector with phase sequence of abc. Find the symmetrical component of currents.

Ia₀ = (100+j50) AIa₁ = (146.41+ j65.47) AIa₂ = (546.41-j165.47) A
Ia₀ = (100+j50) AIa₁ = (546.41+ j165.47) AIa₂ = (546.41-j165.47) A
Ia₀ = (100+j50) AIa₁ = (546.41+j165.47) AIa₂ = (-146.41-j65.47) A
Ia₀ = (100+j50) AIa₁ = (200+ j107.75) AIa₂ = (200-j107.75) A

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP

MGVCL Exam Paper (30-07-2021 Shift 2)
In a 3-phase, 4-wire, 400/230 V system, a lamp (L1) of 100 W is connected to one phase and neutral and a lamp (L2) of 150 W is connected to the second pahse and neutral. If the neutral wire is disconnected accidently, then

100 W lamp (L1) becomes brighter and 150 W lamp (L2) becomes dim
both 100 W lamp (L1) and 150 W lamp (L2) becomes dim
both 100 W lamp (L1) and 150 W lamp (L2) becomes brighter
100 W lamp (L1) becomes dim and 150 W lamp (L2) becomes brighter

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP
