Admittance (Y) is the reciprocal of the impedance of a circuit. Admittance of an AC circuit is analogous to the conductance of a DC circuit. The unit of Admittance is Simen or MHO Admittance = 1/Z simen Y = Conductance ± J Susceptance Or the Admittance can be written as Y = (G ± J B) Simen Now comparing the above equation by the given equation in the question i.e Y= a + jb ∴ a = G = Conductance
Ripple factor: The output of the rectifier is of pulsating d.c. type. The amount of a.c. content in the output can be mathematically expressed by a factor called the ripple factor (γ). The ripple factor expresses how much successful the circuit is, in obtaining pure d.c from a.c. input. Less is the ripple factor, better is the performance of the circuit. Ripple Factor γ = R.M.S value of a.c component of output ⁄ Average or d.c component of the output
Total resistance in the given circuit R = (250 + 250)MΩ = 500 MΩ Current I = V/R = 24/(500 × 103) Now the Voltage in the voltmeter = \dfrac{{24}}{{500 \times {{10}^3}}} \times 250 \times {10^3} V = 12 V
Galvanized steel conductors do not corrode, and possess high resistance. Hence such Wires are used in telecommunications circuits, earth wires, guard wire, stray wire, etc.
The shaded-pole motor is the original type of AC single-phase induction motor. Shaded pole-type single-phase induction motors are provided with shading rings on their poles which are the projected type of poles. The stator of such motors has projected poles like DC machines as shown in Fig. 5.7. The rotor is a squirrel cage type similar to that of split-phase-type motors. The poles are excited by giving a single-phase AC supply. A single-turn thick coil in the form of a ring called the shading ring is fitted on each side of every pole as shown. The portion of the poles where the shading ring is fitted is called the shaded portion, while the other portion is called the unshaded portion. The shaded pole motor has the lowest starting torque as compared to the all single-phase induction motors.
