MGVCL Exam Paper (30-07-2021 Shift 3) As per Stockholm International Peace Research Institute (SIPRI) report 2019 for the period 2014-2018, which country is the largest arms importer in the world? India Saudi Arabia Myanmar Germany India Saudi Arabia Myanmar Germany ANSWER DOWNLOAD EXAMIANS APP
MGVCL Exam Paper (30-07-2021 Shift 3) A star connected synchronous generator rated at 500 MVA, 50 kV has a reactance of 0.5 pu. Find the ohmic value of the reactance. 0.1 Ω 0.25 Ω 2.5 Ω 1 Ω 0.1 Ω 0.25 Ω 2.5 Ω 1 Ω ANSWER EXPLANATION DOWNLOAD EXAMIANS APP pu = actual/baserated phase consired at base value for alternator.ohmic pu = ohmic actual/ohmic basepu = ohmic actual*current base/voltage baseConsider all above phase valuesMVA (3phase) = 3 Vph IphIph = 500*10⁶/(3*28901.73) = 5766.66 Apu = ohmic actual*current base/voltage base0.5 = ohmic actual*5766.66/28901.73ohmic actual = 2.5 Ω
MGVCL Exam Paper (30-07-2021 Shift 3) Two-wattmeter method is used to measure the power taken by a 3-phase induction motor on no load. The wattmeter readings are 400 W and -50 W. Calculate the reactive power taken by the load 450/√3 VAR 350/√3 VAR 450√3 VAR 350√3 VAR 450/√3 VAR 350/√3 VAR 450√3 VAR 350√3 VAR ANSWER EXPLANATION DOWNLOAD EXAMIANS APP Reactive power taken (Q) = √3*(W1 - W2)= √3*(450 + 50)= √3*450 kVAR
MGVCL Exam Paper (30-07-2021 Shift 3) In which of the following situations, there is no need to provide directional overcurrent protection. ring main single end fed, parallel feeder double end fed, single feeder single end fed, single feeder ring main single end fed, parallel feeder double end fed, single feeder single end fed, single feeder ANSWER EXPLANATION DOWNLOAD EXAMIANS APP Directional overcurrent relay protection is used for parallel feeder and ring main system.It is not used for the protection of radial system.
MGVCL Exam Paper (30-07-2021 Shift 3) Murray loop test is performed on a faulty cable 300 m long. At balance, the resistance connected to the faulty core was set at 20 Ω and the resistance of the resistor connected to the sound core was 40 Ω. Calculate the distance of the fault point from the test end. 300 m 100 m 200 m 400 m 300 m 100 m 200 m 400 m ANSWER EXPLANATION DOWNLOAD EXAMIANS APP Where,R2 is the resistance connected to the faulty core in ohmR2 is the resistance of the resistor connected to the sound core in ohmR1 Distance of fault location (Lx) = R2/(R1 + R2)*(2*L)= (20/60)*600= 200 m.
MGVCL Exam Paper (30-07-2021 Shift 3) In public sector, what is the full form of "LIC"? Lively Insurance Corporation Life Insurance Corporation Life Insurance Company Life Insurers Lively Insurance Corporation Life Insurance Corporation Life Insurance Company Life Insurers ANSWER DOWNLOAD EXAMIANS APP
