Type B MCB: Type B devices are generally suitable for domestic applications. They are designed to trip at fault currents of 3 - 5 times rated current.
Type C MCB: Type C devices are the normal choice for commercial and industrial applications These devices are designed to trip at 5 - 10 times rated current
Type D MCB: The Type D devices have more limited applications, normally in industrial use where high inrush currents may be expected. Type D devices are designed to trip at 10 - 20 times.
Bus Type - Known Parameter - Unknown Parameter Load Bus -P, Q - V, phase angle Generator Bus - P, V (magnitude) - Q, Voltage phase angle Slack Bus Voltage - magnitude and phase angle - P, Q
The ratio of full load current to short circuit current = 1/6 Xsc = j/(1/6) External reactance required = j*((1/6) - 0.06)) = j*0.106 pu Full load current = (40*1000)/(√3*15) = 1539.6 A Per unit reactance = j*0.106 = (I*Xr)/V j*0.15 = (1539.6*Xb)/((15/√3)*1000)) = 0.60 ohm
