MGVCL Exam Paper (30-07-2021 Shift 3)
The purpose of ____ is to check the ability of the circuit breaker to withstand the overvoltages at power frequency as well as undesired value of voltage during lightning and other discharge phenomenon.
Die-electric test on Circuit breaker: These tests are performed to check power frequency and impulse voltage withstand capacity. Power frequency tests are kept on a new circuit breaker, the test voltage changes with a circuit breaker rated voltage. In impulse tests, impulse voltage of particular value is employed to the breaker.
Type B MCB: Type B devices are generally suitable for domestic applications. They are designed to trip at fault currents of 3 - 5 times rated current.
Type C MCB: Type C devices are the normal choice for commercial and industrial applications These devices are designed to trip at 5 - 10 times rated current
Type D MCB: The Type D devices have more limited applications, normally in industrial use where high inrush currents may be expected. Type D devices are designed to trip at 10 - 20 times.
1.6 inches = 1.6 inches x 1,000 mils per inch = 1,600 mils 0.25 inch = 0.25 inch x 1,000 mils per inch = 250 mils Area = 1,600 x 250 = 400,000 square mils
The ratio of full load current to short circuit current = 1/6 Xsc = j/(1/6) External reactance required = j*((1/6) - 0.06)) = j*0.106 pu Full load current = (40*1000)/(√3*15) = 1539.6 A Per unit reactance = j*0.106 = (I*Xr)/V j*0.15 = (1539.6*Xb)/((15/√3)*1000)) = 0.60 ohm
Type B MCB: Type B devices are generally suitable for domestic applications. They are designed to trip at fault currents of 3 - 5 times rated current.
Type C MCB: Type C devices are the normal choice for commercial and industrial applications These devices are designed to trip at 5 - 10 times rated current
Type D MCB: The Type D devices have more limited applications, normally in industrial use where high inrush currents may be expected. Type D devices are designed to trip at 10 - 20 times.
