No of disc required for 11 kV transmission line = 1 disc Since the transmission line is 3-phase, therefore, the number of discs required for a single-pole will be 3. Total no. of poles = 80 No of disc = 3 × 80 = 240
Form factor: The ratio of r.m.s (or effective) value to average value is the form factor (Kf) of the Waveform. It has used in voltage generation and instrument correction factors. Peak factor: The ratio of maximum value to the r.m.s value is the peak factor (Kp) of the waveform. Form Factor × Peak Factor = (RMS Value / Average Value) * (Maximum Value / RMS Value) = Maximum Value / Average Value
The combined inductance of two coils connected in series L = L1 + L2 + 2M In series adding case L1 + L2 + 2M = 0.6 H ——–(1) In series opposing case L1 + L2 − 2M = 0.1 H ——–(2) Subtracting eqn (2) from eqn (1) we get 4M = 0.5 H M = 0.125 H Let L1 = 0.2 H (since the coil when isolated, its self-inductance is 0.2 H) Putting the value of M & L1 in equation (2) 0.2 + L2 + 2 ×0.125 = 0.06 0.2 + L2 = 0.35 L2 = 0.15 H
