SSC JE Electrical 2019 with solution SET-2
When capacitors are connected in series across DC voltage then_____

The voltage across each capacitor is the same
The same current flows through each capacitor in a given time
The charge on each capacitor is the same
The charge on each capacitor is the same and the same current flows through each capacitor in a given time

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP

SSC JE Electrical 2019 with solution SET-2
If the AC voltage and current are given by the following expressions?
v = 200sin (314t — 60°)
i = 50sin (720t), then what is the phase relation between them?

Voltage leads current by 60°
Voltage lags current by 60°
Voltage and current are in phase
Can’t be determined

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP

SSC JE Electrical 2019 with solution SET-2
Four relations have been given. Select the correct relation?

MMF = Flux/Reluctance
MMF = Flux/Reluctance
Flux = MMF/Permeance.
MMF = Flux/Permeance

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP

SSC JE Electrical 2019 with solution SET-2
The impedance at resonance offered by a parallel resonant circuit is

Minimum given by L/CR
Maximum given by L/CR
Maximum given by I/CR
Minimum given by I/CR

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP

SSC JE Electrical 2019 with solution SET-2
A series magnetic circuit will have

Same magnetic flux
Two or more paths for magnetic flux
Different magnetic flux
Total reluctance of a series circuit = difference of the reluctances in different parts of the circuit

ANSWER EXPLANATION DOWNLOAD EXAMIANS APP
