The emitter current (IE) of a transistor has two components such as base current (IB) and collector current (IC). The base current (IB) is about 2% of the emitter current (IE), but the collector current (Ia) is about 98% of the emitter current (IE). ∴ IE > IC > IB IE = IB + IC
No of disc required for 11 kV transmission line = 1 disc Since the transmission line is 3-phase, therefore, the number of discs required for a single-pole will be 3. Total no. of poles = 80 No of disc = 3 × 80 = 240
The strength of a magnetic field is specified by the magnetic induction B or by the magnetic field strength H. A current I through a long, straight wire produces a magnetic field with strength H = I/2πr at a distance r from the wire. Given H = 1 A/m I = 10 A H = I/2πr 1 = 10/2πr r = 10/2π
This type of motor is designed to operate with the start winding and it’s series capacitor permanently connected to the supply. lt has two capacitors connected in parallel in the start winding circuit for starting purposes. The running capacitor is employed to correct the power factor. As a result, this motor has a higher starting torque as well as a higher efficiency. These motors are employed in sizes ranging from 375 W to 7.5 kW. The power factor of these motor is upto 80% to 100%.
