Io = V/R = 20/100 Io = 0.2 A Since the given diode is an ideal diode therefore there is no voltage drop across it. Vo = Io × RD Vo = 0.2 × 0 Vo = 0 Hence Io = 0.2 A & Vo = 0
Form factor: The ratio of r.m.s (or effective) value to average value is the form factor (Kf) of the Waveform. It has used in voltage generation and instrument correction factors. Peak factor: The ratio of maximum value to the r.m.s value is the peak factor (Kp) of the waveform. Form Factor × Peak Factor = (RMS Value / Average Value) * (Maximum Value / RMS Value) = Maximum Value / Average Value
Ampere works law or Circuital Law This law relates to work done in a magnetic circuit i.e. closed magnetic flux path. The work done on or by a unit N-pole in moving once round any complete path is equal to the product of current and number of turns enclosed by that path
In the PMMC type instrument, the deflection is directly proportional to the current flowing through the instrument, we get a uniform scale for the instrument. It gives a uniform scale of upto 270° or more. Td ∝ I
