MGVCL Exam Paper (30-07-2021 Shift 3) A group of computers and other devices connected together is called a network and the concept of connected computers sharing resources is called ____ Switching Routing Linking Networking Switching Routing Linking Networking ANSWER DOWNLOAD EXAMIANS APP
MGVCL Exam Paper (30-07-2021 Shift 3) Murray loop test is performed on a faulty cable 300 m long. At balance, the resistance connected to the faulty core was set at 20 Ω and the resistance of the resistor connected to the sound core was 40 Ω. Calculate the distance of the fault point from the test end. 200 m 400 m 100 m 300 m 200 m 400 m 100 m 300 m ANSWER EXPLANATION DOWNLOAD EXAMIANS APP Where,R2 is the resistance connected to the faulty core in ohmR2 is the resistance of the resistor connected to the sound core in ohmR1 Distance of fault location (Lx) = R2/(R1 + R2)*(2*L)= (20/60)*600= 200 m.
MGVCL Exam Paper (30-07-2021 Shift 3) Which feature is used in Ms Word to make the selected sentence to All Capital Letters or All Small Letters? Change sentence Change case Change latter Change capital Change sentence Change case Change latter Change capital ANSWER DOWNLOAD EXAMIANS APP
MGVCL Exam Paper (30-07-2021 Shift 3) What is the value of the characteristic impedance of a transmission line with impedance and admittance of 15 and 5? 0.577 1.414 0.7.7 1.732 0.577 1.414 0.7.7 1.732 ANSWER EXPLANATION DOWNLOAD EXAMIANS APP Characteristic impedance = √(impedance/admittance) = 1.73
MGVCL Exam Paper (30-07-2021 Shift 3) Consider a solar PV plant with the following specific conditions:Analysis period: 1 yearMeasured average solar irradiation intensity in 1 year: 150 kWh/m²Generator area of the PV plant: 10 m² Efficiency factor of the PV modules: 15%Electrical energy actually exported by plant to grid: 135 kWhCalculate the performance ratio. 60% 50% 80% 75% 60% 50% 80% 75% ANSWER EXPLANATION DOWNLOAD EXAMIANS APP Where,A - total solar panel area in meter square.r - efficiency of solar panelh - solar installation per meter square area.Solar panel performance ratio = Actual energy (kWh)/(A*r*h)= (135/(0.15*10*150))= 0.60= 60 % (in percentage)
MGVCL Exam Paper (30-07-2021 Shift 3) The current flowing in to a balanced delta connected load through line 'a' is 10 A when the conductor of line ’b’ is open. With the current in line 'a' as reference, compute the symmetrical components of the line currents. Assume the phase sequence of ’abc’. Ia₀ = 10 A.Ia₁ = (-5 + j2.44) A.Ia₂ = (5 - j2.44) A. Ia₀ = 0 A.Ia₁ = (-1.66 + j2.88) A.Ia₂ = (1.66 + j2.88) A. Ia₀ = 0 A.Ia₁ = (-5 + j2.88) A.Ia₂ = (5 - j2.88) A. Ia₀ = 10 A.Ia₁ = (-1.66 + j2.88) A.Ia₂ = (1.66 + j2.88) A. Ia₀ = 10 A.Ia₁ = (-5 + j2.44) A.Ia₂ = (5 - j2.44) A. Ia₀ = 0 A.Ia₁ = (-1.66 + j2.88) A.Ia₂ = (1.66 + j2.88) A. Ia₀ = 0 A.Ia₁ = (-5 + j2.88) A.Ia₂ = (5 - j2.88) A. Ia₀ = 10 A.Ia₁ = (-1.66 + j2.88) A.Ia₂ = (1.66 + j2.88) A. ANSWER EXPLANATION DOWNLOAD EXAMIANS APP For the given question,Ib = 0Ia = -IcCalculation:Ia1 = 1/3*(Ia + a*Ib + a²*Ic)= 1/3*(10 + 10∟-120°)= 5 + j*2.88 AIa2 = 1/3*(Ia + a²*Ib + a*Ic)= (1/3)*(10 + 10∟120°)= 5 - j*2.88 AIao = (1/3)*(Ia + Ib + Ic)= (Ia - Ia)= 0
