Electric Circuits If 1 A current flows in a circuit, the number of electrons flowing through this circuit is 1.6 × 10 - 19 0.625 × 10 - 19 0.625 × 1019 1.6 × 1019 1.6 × 10 - 19 0.625 × 10 - 19 0.625 × 1019 1.6 × 1019 ANSWER DOWNLOAD EXAMIANS APP
Electric Circuits In a 3 - φ delta connection, two-wattmeter method is used to measure the power; if the two watt meters read 28.13 kW and 13.31 kW, the power factor of connection will be 0.4. 0.85. 0.9. 0.6. 0.4. 0.85. 0.9. 0.6. ANSWER DOWNLOAD EXAMIANS APP
Electric Circuits A delta connection contains three equal impedance of 60 Ω. The impedance of the equivalent star connection for each star load will be 30 Ω. 15 Ω. 40 Ω. 20 Ω. 30 Ω. 15 Ω. 40 Ω. 20 Ω. ANSWER DOWNLOAD EXAMIANS APP
Electric Circuits Three resistances of two ohms each are connected in star. In the equivalent delta representation each resistance will have a value of _______________ Ω. 5.2. 0.6. 6. 3.4. 5.2. 0.6. 6. 3.4. ANSWER DOWNLOAD EXAMIANS APP
Electric Circuits The power dissipated in a pure capacitor is zero. both (B) and (C) above. proportional to the value of capacitance. proportional to applied voltage. zero. both (B) and (C) above. proportional to the value of capacitance. proportional to applied voltage. ANSWER DOWNLOAD EXAMIANS APP
Electric Circuits Three resistances have the following ratings 150 Ω at 5 %, 100 Ω at 5 % and 200 Ω at 5 % respectively. The percentage error when all the three are connected in series will be + 8 %. + 6 %. + 5 %. + 7 %. + 8 %. + 6 %. + 5 %. + 7 %. ANSWER DOWNLOAD EXAMIANS APP
